Olsen LRF65 - Page 2

2
240011511 REV. C [05/31/2017]
Furnace
Model
Cabinet Plenum - Openings
Flue
Filter
(Permanent)
Shipping
Weight
Width
A
Length
B
Height
C
Supply
D x E
Return
F x G
Diameter
Height
H
LRF/
LRFV
22" 53-½" 33-⁵/
8
" 20-½" x 18" 20-½" x 18-⁵/
8
" 5" 29" 20" x 20" x 1" 240 LB
55.8 cm 135.9 cm 85.4 cm 52.1 cm x 45.7cm 52.1 cm x 47.3cm 12.7 cm 73.7cm 51cm x51cm x 2.5cm 108Kg
DIMENSIONS
B
G
1
7
8
"
4.8cm
E
H
D
C
A
F
Table 1 - Dimensions
