DISASSEMBLING/ASSEMBLING PROCEDURE
6. Transformer
(1) Remove the four screws which secure the
transformer to the chassis.
Phillips screwdriver No. 2
(2) Remove the transformer from the chassis.
7. Frame
(1) Remove the three screws which secure the
frame to the chassis.
Phillips screwdriver No. 2
(2) Remove the frame from the chassis.
8. Diaphragm
(1) Remove the three screws which secure the.
diaphragm to the chassis.
5-5
Phillips screwdriver No. 2
(2) Remove the diaphragm from the chassis.
