112 EN
Information/Separately sold accessories
10
 Using a diopter adjustment dial
Turn on the camera power, and then set the diopter adjustment dial to a position at
which an image is visible in the view  nder.
• The angle can be changed up to a maximum 90°.
u
button
Eye-sensor
Diopter adjustment dial
 Manually switching between the view nder and monitor
Set the automatic switch to off, and control the switching using the
u
button on the
external view nder.
1
In the # Accessory Port Menu, select [CEVF] and press the Q button.
2
Select [EVF Auto Switch] and press the Q button.
• The same menu can also be displayed by pressing and holding the
u
button on the
VF-4.
3
Select [Off] and press the Q button.
• Press the
u
button on the external view nder to switch between the display
between the view nder and monitor.
 Main Speci cations (VF-4)
Display pixels Approx. 2,360,000 dots
Field of view 100 %
View nder
magni cation
Approx 1.48 (-1 m
-1
50 mm lens/in nity)
Eye point Approx. 21 mm (-1 m
-1
) (from the back of eyepiece lens)
Diopter adjustment
range
-4.0 to +2.0 m
-1
Weight 42 g (0.09 lb) (without connector cover)
Dimensions 30.4 mm (W) × 48.2 mm (H) × 47.8 mm (D)
(1.2” × 1.9” × 1.9”)
# Cautions
• When carrying the camera, do not hold it by the view nder.
• Do not allow direct sunlight to pass into the view nder through the eyepiece lens.
