68
EN
Playback options
5
Image overlay
Up to 3 frames of RAW images taken with the camera can be overlaid and saved as a
separate image. The image is saved with the record mode set at the time the image is
saved. (If [RAW] is selected, the copy will be saved in [YN+RAW] format.)
1
With a RAW image displayed during playback, press Q and select
[Image Overlay].
2
Select the number of images in the overlay and press Q.
3
Use FGHI to select the RAW images that
will be used in the overlay and press
Q
to
select.
When you have selected the number of images
specifi ed in Step 2, the overlay will be displayed.
•
RAW RAW RAW
RAW
RAW RAW RAW
Image Overlay
Back Set
4
Adjust gain.
Use HI to select an image and use FG to adjust
gain.
Gain can be adjusted in the range 0.1 – 2.0. Check the
results in the monitor.
•
•
×1.5×1.5×0.3 ×0.5
Image Overlay
Back Set
5
Press Q. A confi rmation dialog will be displayed; select [Yes] and press
Q.
% Tips
To overlay 4 or more frames, save the overlay image as a RAW fi le and use
[Image Overlay] repeatedly.
Audio recording
Add an audio recording (up to 30 sec. long) to the current photograph.
1
Display the image to which you want to add an
audio recording and press Q.
Audio recording is not available with protected images.
Audio recording is also available in the playback menu.
2
Select [R] and press Q.
To exit without adding a recording, select [No].
•
•
•
JPEG
m
R
<
Rotate
JPEG Edit
Back
Set
3
Select [R Start] and press Q to begin
recording.
To stop recording part-way through, press Q.
4
Press Q to end recording.
Images with audio recordings are indicated by a H
icon.
To delete a recording, select [Erase] in Step 2.
•
•
•
R
R
Start
No
Erase
Back Set
•
