5
Quick Start Guide ENGLISH
Please note:
WLAN Disclaimer
Selecting the WLAN channel
When using several OLYMPUS EP50 cameras simultaneously, we
recommend to use a different WLAN channel for each camera. This
avoids interference between the individual cameras. Open the
Settings > Network
dialog box in the OSD software and select the
AP
tab. Note that some countries recommend the use of certain WLAN
channels:
Using the camera in LAN mode
In LAN mode, the camera connects to a network (LAN). The USB
Ethernet adapter must be plugged into the camera for this to work
and the network cable must be plugged in, too. When the network
(LAN) is equipped with the necessary hardware (WLAN router or
Access Point), you can control the camera via WLAN with your
mobile devices.
Active OLYMPUS EP50 cameras are automatically recognized by
the EPview software or the EPview app and they are displayed as
a thumbnail.
If active OLYMPUS EP50 cameras cannot be recognized auto-
matically (for example, because they are connected to a different
network), you can manually add them by entering the IP address in
the EPview software or EPview app. To do so, contact your local
network administrator. You can find more information in the EPview
user manual.
The camera can communicate wirelessly via the existing USB interface
using a WLAN adapter. However, the WLAN adapter is not part of the
scope of delivery and you are solely responsible for selecting, using and
operating this accessory device. In particular, you must ensure that the
WLAN adapter you are using has a corresponding radio license in your
region. You are solely responsible for the functionality of the WLAN
network. Possible sources of interference in the WLAN network can also
influence the camera's functionality and performance.
Country Channel Remark
USA 1, 6, 11 IEEE 802.11 g/n (2.4 GHz) 22/20 MHz; channels 12,13 not allowed
Other countries 1, 5, 9, 13 IEEE 802.11 g/n (2.4 GHz) 20 MHz
