EN 9
Attaching to the camera
x
Notes
Confi rm that both the camera and electronic fl ash are off. Attaching or removing the electronic
fl ash while either the fl ash or the camera is on may result in malfunction.
1
Remove the camera hot shoe cover and retract the
lock pin by rotating the lock ring as shown (
1
).
Rotate the lock ring in the direction opposite to that
shown by the “LOCK” arrow until it stops.
2
Slide the fl ash securely into the hot shoe until it clicks
into place (
2
).
3
Turn the lock ring securely in the direction of
“LOCK” (
3
).
•
If the camera has an external fl ash connector, a fl ash bracket and bracket cable (sold
separately) can be hooked up.
