Chapter 10 Specifications
10.1 i- SPEED Camera
` Camera physical
Dimensions
Size W 106mm x H 98mm x L 264mm nominal
Weight 2kg nominal
Mechanical connections
Tripod mounting
1x standard tripod mount (¼” Whitworth thread)
Lens mounting Standard C--mount
Back focus Nominal position 17mm. C--mount can be screwed
in 1mm & out 3mm.
Rotary control locks the C--mount in position
Accessory mounting
4x ¼” Whitworth thread fixing holes on the base
` Electrical connections
Power input Lemo EGG.OB.304.CLV
Pinout 1 Ground 3 +12V
2 +12V 4 Ground
Input voltage
12VDC ±10%
Power consumption Camera: 28W max
System: 36W max
Fuse
Type 20 x 5mm cartridge (coin slot screw access)
Rating 3.15AH 250V
Controller Connector
Standard LVDS c onnector, 26 way MDR
Feature connector 26 way high density D sub female
Pinout 3 Trigger input 4 Trigger ground
Trigger in Level: 5V TTL, 12V maximum
Impedance: 10k ohms (pulled to +5V for trigger switch)
