FLUSHING PUMP OFP
2
1.2 Features
FIGURE 1-2
Autoclavable 1 litre
fluid container
ON/OFF
power switch
Peristaltic pump
Footswitch
connection port
Label 1
Label 2
Rear panel
Flow control
Autoclavable
irrigation tube
Remote control
cable connection
Label 3
IEC power receptacle
(with integral fuses)
Potential equalisation terminal
Fluid container
strap
Fluid container
holder
1.3 Labels
Label 1 -- Refer to Instructions
Label 2 -- Footswitch connection port
Label 3 -- Rating plate
2010--06
Label 4 -- “USE BY” Indicates the last month during which the device is intended to be used.
eg: June 2010 becomes 2010--06
(label 4 is affixed to the irr igation tube).
