Olympus Stylus 1 User Manual

7 EN
Preparations for shooting
1
Inserting and removing the battery and card
1
Follow Steps 1 and 2 to open the
battery/card compartment cover.
• Turn off the camera before opening the battery/
card compartment cover.
2
1
Battery/card compartment lock
Battery/card compartment cover
2
Insert the battery while sliding the battery
lock knob in the direction of the arrow.
• Insert the battery as illustrated with the direction
indicating mark toward the back side of the
camera.
• Slide the battery lock knob in the direction of the
arrow to unlock, and then remove the battery.
Battery
lock knob
Direction
indicating mark
3
Insert the card straight until it clicks into
place.
• Always use SD/SDHC/SDXC cards or Eye-Fi
card with this camera. Do not insert other types of
memory cards. g “Using the card” (P. 100)
• Do not touch the metallic parts of the card
directly.
Write-protect switch
To remove the card
Press the card in until it clicks and comes out
slightly, then remove the card.
4
Follow Steps 1 and 2 to close battery/
card compartment cover.
• When using the camera, be sure to close the
battery/card compartment cover.
2
1

Olympus Stylus 1 Specifications

General

Megapixel	12 MP
Camera type	Bridge camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3968 x 2976 pixels
Image sensor size (W x H)	7.3 x 5.5 mm
Still image resolution(s)	2560 x 1920
Digital zoom	- x
Optical zoom	10.7 x
Focal length range	6 - 64.3 mm
Maximum aperture number	2.8
Minimum aperture number	-
Number of aspheric elements	8
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto/Manual
Auto Focus (AF) points	35
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.05 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 12800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash range (tele)	0.8 - 10.3 m
Flash range (wide)	0.1 - 10.3 m
Video resolutions	320 x 240, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	PCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
PictBridge	No
USB version	2.0
HDMI connector type	Micro
Scene modes	Beach, Documents, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Flash, Fluorescent, Shade, Sunny, Tungsten
Self-timer delay	2, 12 s
Power source type	Battery
Battery type	BLS‑5
Material	Metal
Product color	Black
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	56.5 mm
Width	116.2 mm
Height	87 mm
Weight	- g
Weight (including battery)	402 g
