91
EN
Using separately sold accessories
11
3
Adjust the settings for each group in the super control panel.
250250 F5.6
0.0
0.0
P
3838
A Mode
TTL
M
Off
+5.0
TTL +3.0
1/8
1
Ch
Flash intensity value
Group
Select the flash control
mode and adjust the flash
intensity separately for
each group. For MANUAL,
select the flash intensity.
# Sync
Channel
Set the communication
channel to the same
channel used on the flash.
Flash intensityFlash control
mode
Adjust settings for the camera
flash unit.
4
Press the flash switch to pop up the internal flash.
After confirming that the built-in and remote flash units have charged, take a test
shot.
Wireless flash control range
Position the wireless flash units with their
remote sensors facing the camera. The
following illustration shows the approximate
ranges at which the flash units can be
positioned. The actual control range varies with
local conditions.
5m
3m
100°100°
50°
50°
50°
50°
60°
60°
30°
30°
30°
30°
# Cautions
We recommend using a single group of up to three remote flash units.
Remote flash units can not be used for second curtain slow synchronization longer than
4 seconds.
If the subject is too close to the camera, the control flashes emitted by the built-in flash
may affect exposure (this effect can be reduced by reducing the output of the built-in flash
by, for example, using a diffuser).
Other external flash units
Observe the following precautions when mounting an external flash unit not designated
for use with this camera on the camera hot shoe:
Using obsolete flash units that apply currents of more than about 24 V to the camera hot
shoe X-contact will damage the camera.
Connecting flash units with signal contacts that do not conform to Olympus specifications
may damage the camera.
Use only with the camera in shooting mode M at ISO settings other than [AUTO].
Flash control can only be performed by manually setting the flash to the ISO sensitivity
and aperture values selected with the camera. Flash brightness can be adjusted by
adjusting either ISO sensitivity or aperture.
Use a flash with an angle of illumination suited to the lens. Angle of illumination is usually
expressed using 35-mm format equivalent focal lengths.
