Olympus Stylus 1 User Manual

90 EN
Using separately sold accessories
11
11
Using separately sold accessories
Eyecup
You can exchange this for a larger eyecup
(EP-11).
Removing
Using external flash units designated for use with
this camera
With this camera, you can use one of the separately sold external flash units to achieve
a flash suited to your needs. The external flashes communicate with the camera,
allowing you to control the camera’s flash modes with various available flash control
modes, such as TTL-AUTO.
An external flash unit specified for use with this camera can be mounted on the camera
by attaching it to the camera’s hot shoe. You can also attach the flash to the flash
bracket on the camera using the bracket cable (optional). Refer to the documentation
provided with the external flash units as well.
Functions available with external flash units
Optional flash Flash control mode GN (Guide number) (ISO100)
FL-14
TTL-AUTO, AUTO, MANUAL
GN14 (28 mm*)
FL-36R GN36 (85 mm*) GN20 (24 mm*)
FL-50R GN50 (85 mm*) GN28 (24 mm*)
FL-300R GN20 (28 mm*)
FL-600R GN36 (85 mm*) GN20 (24 mm*)
* The focal length of the lens that can be used (Calculated based on 35 mm film camera).
Wireless remote control flash photography
External flash units that are designated for use with this camera and have a remote
control mode can be used for wireless flash photography. The camera can control the
flash units in up to three separate groups. See the instruction manuals provided with
the external flash units for details.
1
Set the remote flash units to RC mode and place them as desired.
• Turn each flash unit on, press the MODE button, and select RC mode.
• Select a channel and group for each flash unit.
2
Select [On] for [# RC Mode] in
J
Shooting menu 2 (P. 46).
• The super control panel switches to RC mode.
• You can choose a super control panel display by repeatedly pressing the INFO
button.
• Select a flash mode (note that red-eye reduction is not available in RC mode).

Olympus Stylus 1 Specifications

General

Megapixel	12 MP
Camera type	Bridge camera
Sensor type	BSI CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3968 x 2976 pixels
Image sensor size (W x H)	7.3 x 5.5 mm
Still image resolution(s)	2560 x 1920
Digital zoom	- x
Optical zoom	10.7 x
Focal length range	6 - 64.3 mm
Maximum aperture number	2.8
Minimum aperture number	-
Number of aspheric elements	8
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto/Manual
Auto Focus (AF) points	35
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.05 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 12800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash range (tele)	0.8 - 10.3 m
Flash range (wide)	0.1 - 10.3 m
Video resolutions	320 x 240, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	PCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
PictBridge	No
USB version	2.0
HDMI connector type	Micro
Scene modes	Beach, Documents, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Flash, Fluorescent, Shade, Sunny, Tungsten
Self-timer delay	2, 12 s
Power source type	Battery
Battery type	BLS‑5
Material	Metal
Product color	Black
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	56.5 mm
Width	116.2 mm
Height	87 mm
Weight	- g
Weight (including battery)	402 g
