2.2 Nomenclature
TB-0545PC/IC/FC, TB-0535PC/IC/FC, TB-0520IC, TB-0510IC
INSTRUCTION MANUAL
Ch.2
Torque wrench (provided)
For connecting the transducer (available separately) to the THUNDERBEAT instrument.
The torque wrench is also available separately (MAJ-1983 Torque
Wrench/Stabilizer Kit).
No. Nomenclature Description
1 Head Mounts on the knob of the instrument.
2 Assembly index THIS SIDE UP.
3 Grip During use, it is held.
4 Assembly index Securing direction.
