Olympus THUNDERBEAT TB-0545PC - Specifications; Transportation, Storage, and Operating Environments

2.3 Specifications
17
TB-0545PC/IC/FC, TB-0535PC/IC/FC, TB-0520IC, TB-0510IC
INSTRUCTION MANUAL
Ch.2
 Transportation, storage, and operating environments
 Specifications
2.3 Specifications
Operating
environment
Ambient temperature 10 – 40C (50 – 104F)
Relative humidity 30 – 85%
Atmospheric
pressure
70 – 106 kPa
Altitude 3000 m or less
Transportation and
storage environment
Ambient temperature –40 to +60C (–40 to +140F)
Relative humidity 10 – 90%
Atmospheric
pressure
70 – 106 kPa
Model Pistol grip – – TB-0535PC TB-0545PC
Inline grip TB-0510IC TB-0520IC TB-0535IC TB-0545IC
Front-actuated
grip
– – TB-0535FC TB-0545FC
Frequency 47 kHz
Amplitude 80 µm
Dimensions Shaft outer
diameter
ø5.5mm
Effective length 100 mm 200 mm 350 mm 450 mm
Rated high-frequency
(RF bipolar) voltage
229 Vp
Duty cycle (Normal cycle) ON: 5 s/OFF: 10 s
Level setting
(SEAL&CUT mode)
Output levels for the energy of combined ultrasonic and high-
frequency (RF Bipolar)
(Time lag from the beginning of high-frequency to the beginning of
ultrasonic)
 Level 1: 0 s
 Level 2: 0.5 s
 Level 3: 1 s
Level setting
(SEAL mode)
Output levels for the energy of combined ultrasonic and high-
frequency (RF Bipolar)
(Minimum time of output)
 Level 1: 3 s
 Level 2: 4 s
 Level 3: 5 s
