2.2 Nomenclature
TB-0545PC/IC/FC, TB-0535PC/IC/FC, TB-0520IC, TB-0510IC
INSTRUCTION MANUAL
Ch.2
THUNDERBEAT Transducer (separately available)
No. Nomenclature Description
1 THUNDERBEAT
instrument
connection
Is connected to the instrument.
2 Transducer cord Electrical signal is output from the ultrasonic generator to the instrument.
3 Transducer plug Connects to the THUNDERBEAT socket of the ultrasonic generator.
4Symbol for
THUNDERBEAT
Indicates that this is a THUNDERBEAT transducer.
5 Switch contacts The switch contacts conduct the handswitch signal.
