3.6 Inspection of ancillary equipment
TB-0545PC/IC/FC, TB-0535PC/IC/FC, TB-0520IC, TB-0510IC
INSTRUCTION MANUAL
Ch.3
Inspecting the system
• During the inspection, also refer to the instruction manual for THUNDERBEAT
Transducer, ultrasonic generator, and compatible electrosurgical generator.
• After the transducer plug is connected to the generator and the ultrasonic generator
is turned ON, the generator touch-screen should show the corresponding symbol
that is identical to the symbol on the transducer plug. If these symbols are not
identical, the ultrasonic generator or transducer may malfunction. If this occurs,
immediately stop using the system and contact Olympus.
3.6 Inspection of ancillary equipment
1 Prepare and connect ancillary equipment to be used with the THUNDERBEAT by
referring to their respective instruction manuals.
2 Inspect the system by referring to the instruction manual for the ultrasonic generator.
3 Confirm that the selected output level is appropriate for the procedure to be
performed.
• If the selected output level is not appropriate, press the plus or minus button to set
the appropriate output level.
• When both the THUNDERBEAT and the SONICBEAT are connected, set the
output level in the corresponding “Set screen” (referring to Section 5.4, “Output
setting” in the instruction manual for the ultrasonic generator).
To Next Page
