3.6 Inspection of ancillary equipment
29
TB-0545PC/IC/FC, TB-0535PC/IC/FC, TB-0520IC, TB-0510IC
INSTRUCTION MANUAL
Ch.3
 Output mode
 Correlation between cutting speed and output level in SEAL &
CUT mode
Tabl e 3. 3
Output
Mode
Energy
Output Level
(Default Level)
Main Purpose Characteristics
SEAL &
CUT
Ultrasonic +
High frequency
(RF bipolar
output)
1 – 3
(1)
Tissue
sealing/cutting
Blood vessel
sealing/cutting
• This mode is same as the setting 39 of
FineCoag mode of the ESG-400.
• The output setting that has been validated
for vessel sealing is level 1.
• The lower the output level setting is the
faster the cutting speed will be.
• The higher the output level setting is the
longer the RF bipolar output time will be.
• The sealing performance is not changed
regardless of the output level.
SEAL
High frequency
(RF bipolar
output)
1 – 3
(3)
Tissue
sealing/
hemostasis
Blood vessel
sealing/
hemostasis
• This mode is same as the setting 42 of
HardCoag mode of the ESG-400.
• The output setting that has been validated
for vessel sealing is level 3.
• The higher the output level setting is the
longer the RF bipolar output time will be.
Tabl e 3. 2
* For the high-frequency (RF bipolar) output of SEAL & CUT and SEAL mode,
refer to the instructions manual for the compatible electrosurgical generator.
Output level 123
Cutting speed
indicator bars
3 (High/Fast) 2 (Middle/Median) 1 (Low/Slow)
