10
Parts Breakdown
Model HLC300 19476
Item
No.
Description Position
Item
No.
Description Position
Item
No.
Description Position
24493 Bolt 1 27179 Isolated Sheath 17 24525 Magnet Steel 33
24494 Handle Bar 2 27179 Gear 18 24526 Knife 34
24495 Nylon Gasket 3 27179 Block Circle 19 24527 Body 35
24496 Pressing Piece 4 27179 Anchor Sheath 20 24528 Microswitch 36
24497 Input Body 5 24513 Belt Wheel 21 24529 Waved Bolt 37
24498 Anchor Knob 6 24514 Seat of Body 22 24530 Switch 38
24499 Spring 7 24515 Electric Box 23 24531 Strapped Wheel 39
24500 Gasket 8 24516 Bottom Board of Electric Box 24 24532 Belt 40
24501 Pin 9 24517 Bottom Board of Body 25 24533 Motor 41
24502 Anchor Spindle 10 24518 Magnet Steel 26 24534 Gasket 42
24503 Knife Disc 11 24519 Umbrella Bolt 27 24535 Gasket 43
24504 Drain Disc 12 24520 Steel Sheath 28 24536 Bolt 44
27179 Anchor Board 13 24521 Nut 29 24537 Gear Cover 45
27179 Pin 14 24522 Adjusting Bolt 30 24538 Bolt 46
27179 Oil Envelope 15 24523 Plastic Pressing Stick 31 Microswitch 47
27179 Central Spindle 16 24524 Seat of Magnet 32
To Next Page
