OMCN 112/A - Spare Parts List

19
ENGLISH
ENG
16.2 SPARE PARTS LIST
Ref. Name
1 Handle
3 Handle hub
4 Handle setscrew
6 Pin for small piston
8 Bush for piston pivot
9 Self-locking screw
10 Pivoting wheel
12 Pump
13 Stop ring
14 Arm return spring
15 Arm
16 Arm connecting rods
17 Plate-holder
18 Plate
19 Snap ring
20 Washer for articulated joint
21 Connecting rod fastening nut
22 Pedal
23 Arm-bearing pivot
24 Screw washer
25 Pivot fastening screw
26 Stop rings
27 Truck
28 Fastening pin
30 Front wheel
31 Stop ring
32 Drain valve drive pin
33 O-Rings
35 Spring
36 Drain valve body
37 O-Ring
38 Ball
39 Spring
40 Spring fastening plug
41 Plug gasket
42 Plug for ball set
43 Check valve ball
44 Suction valve ball
45 Pump cylinder
46 Plug
Ref. Name
48 Pumping piston
49 Piston gasket
50 O-Rings for cylinder
52 Piston return spring
53 Cylinder
54 Washer
55 Piston gasket
56 Gasket holder and guide
57 Piston
58 O-Ring
59 Spring plug
60 O-Rings
61 Copper gasket
62 Ball-presser spring
63 O-Rings
64 Snap rings
65 O-Ring
66 Pedal pivot
67 Snap ring
68 Drain valve presser
69 Valve presser dowel
71 Wheel pivot
72 Snap ring
73 Filter magnet
74 Pump-holding pivot
75 Pump
76 Plug
77 Slider
78 O-Ring
79 Spring
80 Ball presser
81 Maximum pressure ball
82 Instruction manual
83 Complete set of adhesives
84 Name plate
85 Compete gasket kit
