OMEGA AIR RDP Series User Manual

9
3.2 Specifications
TECHNICAL SPECIFICATIONS
Max. operating pressure
14 bar
g
Max. inlet air temperature
55 °C (for temperature ≠ 35 °C apply correction factor)
Operating ambient temperature
1,5 °C to 45 °C (for temperature > 25 °C apply correction factor)
Pressure dew point
+ 3 °C
Filter requirement (inlet)
Prefilter 3 μm
Communication
RS-485, MODBUS
Digital input
Remote ON/OFF
Type of cooling
Air cooled
Compressor operation
Non-cycling
Condensate drain
Automatic (Zero loss type)
Voltage, Frequency
230 V, 50 Hz (RDP 20-600)
400V, 50 Hz (RDP 750-1900)
Refrigerant
R134a
Protection class (controller front)
IP 65
Handling option
Manual (RDP 20-100), Forklift (RDP 140-1900)
MATERIALS
Casing
Carbon steel
Casing corrosion protection
Epoxy powder paint
Evaporator
Brazed plate stainless steel
Evaporator insulation
Polyurethane foam
Condenser
Copper tube, aluminium fins
Compressor
Carbon steel
Refrigerant piping
Copper
Controller enclosure
Plastic
SIZES
Compressed air
Electrical connection
Ambient air
Refrigerant
Dimensions & Mass
Model
(3)
Flow
Connection
Pressure
drop
Power supply
(4)
Power/
Consumption
Cooling
flow
Heat
rejec.
Type
Mass
W x L x H
Net
m
3
/h
bar
Ph~V-Hz
kW
m
3
/h
kW
kg
mm
kg
RDP 20
20
G 3/8” BSP-F
0,2
1~230-50*
0,160 / 0,135
250
0,2
R134a
0,190
352 x 485 x 499
25
RDP 35
35
G 3/8” BSP-F
0,2
1~230-50*
0,170 / 0,135
250
0,3
R134a
0,230
352 x 485 x 499
25
RDP 50
50
G 3/4” BSP-F
0,2
1~230-50*
0,20 / 0,18
250
0,4
R134a
0,330
352 x 485 x 499
26
RDP 75
75
G 3/4” BSP-F
0,2
1~230-50/230-60
0,40 / 0,25
250
0,6
R134a
0,380
352 x 485 x 499
27
RDP 100
100
G 3/4” BSP-F
0,2
1~230-50/230-60
0,45 / 0,32
400
0,8
R134a
0,585
352 x 485 x 499
32
RDP 140
140
G 1” BSP-F
0,2
1~230-50/230-60
0,50 / 0,38
700
1,1
R134a
0,61
357 x 552 x 684
50
RDP 180
180
G 1” BSP-F
0,2
1~230-50*
0,60 / 0,45
700
1,5
R134a
0,71
357 x 552 x 684
52
RDP 235
235
G 1” BSP-F
0,2
1~230-50*
0,73 / 0,60
700
1,9
R134a
0,89
357 x 552 x 684
56
RDP 300
300
G 1 1/4” BSP-F
0,2
1~230-50/230-60
1,20 / 0,95
1100
2,4
R134a
1,07
496 x 589 x 827
84
RDP 380
380
G 1 1/4” BSP-F
0,2
1~230-50/230-60
1,40 / 1,08
1100
3,1
R134a
1,20
496 x 589 x 827
90
RDP 480
480
G 1 1/2” BSP-F
0,2
1~230-50/230-60
1,45 / 1,20
1100
3,9
R134a
1,31
496 x 589 x 827
99
RDP 600
600
G 2” BSP-F
0,2
1~230-50/230-60
1,50 / 1,25
2200
4,9
R134a
1,59
491 x 710 x 973
110
RDP 750
750
G 2” BSP-F
0,2
3~400-50/440-60
2,2 / 1,6
2200
6,1
R134a
2,19
491 x 710 x 973
120
RDP 950
950
G 2” BSP-F
0,2
3~400-50/440-60
2,7 / 2,1
2200
7,7
R134a
2,55
491 x 710 x 973
150
RDP 1150
1150
G 2 1/2” BSP-F
0,2
3~400-50/440-60
2,8 / 2,2
1900
9,4
R134a
3,49
663 x 856 x 1534
250
RDP 1300
1300
G 2 1/2” BSP-F
0,2
3~400-50/440-60
3,2 / 2,6
1900
10,6
R134a
3,25
663 x 856 x 1534
280
RDP 1500
1500
G 2 1/2” BSP-F
0,2
3~400-50/440-60
3,3 / 2,7
4600
12,2
R134a
5,00
663 x 856 x 1534
290
RDP 1900
1900
G 2 1/2” BSP-F
0,2
3~400-50/440-60
4,2 / 4,0
3800
15,5
R134a
5,30
663 x 856 x 1534
310
RDP 2600
2600
DN100
0,2
3~400-50*
8,0 / 3,3
4000
16,1
R134a
8,0
1044 x 1467 x 1797
500
↓ Larger sizes available upon request ↓
(3)
Nominal conditions: inlet flow 20 °C at 1 bar
a
, ambient 25 °C, dryer inlet 35°C at 7 bar
g
, 3 °C pressure dew point (-20,5 °C atmospheric).
(4)
For 60 Hz 20 % more than stated, consumption at nominal conditions.
* Special 60 Hz version available.
