Omega CND3 Series User Manual

3
EVENT inputs/ CT function (optional) 1
0: None, 1: Event Input3, 2: RS-485 Communication
EVENT inputs/ CT function (optional) 2
0: None, 1: Event Input2, 2: CT measure input2.
EVENT inputs/ CT function (optional) 3
0: None, 1: Event Input1, 2: CT measure input1.
 Specifications
Input Voltage 80 ~ 260Vac 50/60Hz; 24Vac 50/60Hz ±10%; 24 Vdc ±10%
Power Consumption 8VA max.
Display Method LCD display. Process value (PV): Yellow color, Set point (SV): Green color
Sensor Type
Thermocouple: K, J, T, E, N, R, S, B, L, U, TXK
(Thermal couple measuring location are not intended to be directly connected to the MAINS supply.)
3-wire Platinum RTD: Pt100, JPt100
Resistance: Cu50, Ni120
Analog input: 0 ~ 5Vdc, 0 ~ 10Vdc, 0 ~ 20mA, 4 ~ 20mA, 0 ~ 50mVdc
Control Mode
PID, PID program control (Ramp/Soak control), FUZZY, Self-tuning, Manual and On/FF
Control Output
Relay output: Max. load 250Vac, 5A resistive load
Voltage pulse output: 12Vdc, Max. output current 40mA
Current output: DC 4 ~ 20m A output (Load resistance: Max. 500Ω)
Analog voltage output: 0 ~ 10Vdc
Alarm Output Type Relay output: Max. load 250Vac, 3A resistive load
Display Accuracy 0 or 1 digit to the right of the decimal point (selectable)
Sampling Rate Analog input: 0.1 sec/ per scan; Thermocouple or Platinum RTD: 0.1 sec/per scan
Vibration Resistance
10 to 55Hz, 10m/s
2
for 10min, each in X, Y and Z directions
Shock Resistance
Max. 300m/ s
2
, 3 times in each 3 axes, 6 directions
Ambient Temperature
0°C ~ +50°C
Storage Temperature
-20°C ~ +65°C
Altitude
Max. 2000m
Relative Humidity 35% ~ 80% RH（non-condensing）
 Operation
 There are three modes of operation: operation, regulation and initial setting. When power is applied, controller gets into the operation
mode. Press the
key to switch to regulation mode. If the key is pressed for more than 3 seconds, controller will switch to the
initial setting mode. Pressing the
key while in the regulation mode or initial setting mode, forces the controller to return to the
operation mode..
 PV/SV: Sets the temperature set point and displays the temperature process value. Use
keys to set the temperature set
point.
 Setting method: While in any function mode, press the
key to select the desired function and use keys to change
settings. Press
key to save the changes.
 The flow chart below shows how to switch the settings and internal functions:
Regulation Mode Operation Mode
Initial Setting Mode
Press key less than 3 sec
Press key
Press key more than 3 sec
Press key
【Operation Mode】Parameter Setting:
Display
Description
Factory Setting
Use
to set temperature set point, use to switch between the display parameter
RUN/ST
OP: Co
n
trol setting RUN
or ST
OP
RUN
PATTERN: Sta
r
t
pattern setting (s
et control mode t
o PROG mode
)
0
STEP: Start step
setting (set contr
o
l mode to PR
OG mode
)
0
SELECT POI
N
T:
Decimal point setting (0: integral ;
1: one decimal point)
1
LOCK: Setting lo
ck mode (LOCK
1
: all; LOCK2: onl
ySV and
F1/F2 k
ey is allowed)
OFF
ALARM1 HI
GH:
Upper limit alarm
1 (displa
y
accor
ding to the setting in ALARM mode)
4.0
ALARM1 LOW: L
o
wer limit alarm 1 (displa
y
accord
ing to the setting in ALARM mode)
4.0
