Omega DP25-S - Wire DC Input Connections with External Excitation; Current Input Connections with Internal Excitation

3
Getting Started
16
3.4 CONNECTING SENSOR INPUTS (Continued)
Figure 3-8. 4-Wire DC Input Connections with External Excitation
Figure 3-9. Current Input Connections with Internal Excitation
