CIBANO 500 Getting Started
10 OMICRON
3.2.1 Front panel
Figure 3-1: Front view of CIBANO 500
WARNING
Death or severe injury caused by high voltage or current possible
► Do not cover the warning lights (for example, with a computer) since the warning lights
indicate possible hazards.
► Always observe the warning lights while working with CIBANO 500.
Emergency Stop button
Press the button to immediately shut
off all current and voltage outputs.
See 3.2.4 "Emergency Stop button"
on page 13
Measurement Start/Stop button
Press the button to enable the
CIBANO 500 outputs and start a
measurement.
Press the button once more to stop
the measurement.
Warning lights indicating safe operation and
possible hazardous voltage and/or current
levels at the CIBANO 500 outputs
See Table 3-1: "Warning lights" on page 13.
