Omicron COMPANO 100 Getting Started

Side view:
Connector for battery charger
(magnetically attached).
Connector for external safety functions;
serves to connect OMICRON safety
accessories.
Visit the OMICRON website for details.
4 mm/0.16 " banana socket or cable shoe connector
for an additional PE connection (to connect to low
resistance grounding bars, for example).
OMICRON-supplied battery charger.
Note: You can remove the dongle shown in the picture above (the connector for external safety
functions) to protect COMPANO 100 from unauthorized usage.
WARNING
Death or severe injury can occur if the appropriate safety instructions are not
observed.
The OMICRON-supplied charger has a magnetically attached power connector.
Magnets can impact the function of pace makers and implantable cardioverter-
defibrillators (for example, actuation of reed switch).
► Keep a minimum distance of 20 cm/8 inch between the magnetic connector and the
implanted devices to prevent malfunction and danger to health.
Getting Started with COMPANO 100
18
OMICRON
