SUPPLY
VOLTAGE (V) 230
ABSORBED POWER (kW) REFER TO DATA ON PLATE
MASS (kg) REFER TO DATA ON PLATE
DIMENSIONS (mm) REFER TO PARAGRAPH 2.5
MAXIMUM LOAD WEIGHT (kg) REFER TO DATA ON PLATE
ROTATION SPEED (RPM) 12
ROTATION WISE CLOCKWISE
2.4 PLATES AND PICTOGRAMS
Please find below a list of the warning pictograms and plates located on the machine.
INDICATES DANGEROUS VOLTAGE.
MEANS DANGER OF COMPRESSION OF THE UPPER LIMBS.
Omni SUPERPLUS EN IGM_REV6 17
