The
standard height of the machine is 2500 mm, according to the Client’s needs, the machine can
be 2000 mm, 3000 mm or 3500 mm high.
H=2
500 (STANDARD) H=2000 (OPTIONAL) H=3000 (OPTIONAL) H=3500 (OPTIONAL)
2.6 NECESSARY SPACE
The necessary space for using and maintaining the machine can be deduced from the dimensions
of the machine itself and from the need to load pallets onto the rotating platform. Under normal
usage and maintenance conditions it should therefore be possible to operate comfortably, without
any obstacles to accessing the machine, in any of its parts.
2.7 ELECTRICAL TOLERANCES OF THE MACHINE
Wor
king voltage: the electrical equipment is designed to operate a nominal voltage of 230 V.
Any
variations will compromise the life of the electrical equipment. If variations larger than the standard
values are foreseen, please contact the machine Builder
.
2.8 POWER EQUIPMENT
The label with the power equipment data is located in a readable position. On it there are written
the builder’s name, the symbol CE, the serial number, the supply voltage and the absorbed power
data, in accordance with regulations currently in force.
2.9 ELECTROMAGNETIC ENVIRONMENT
The machine can run in a correct way both in an industrial and in a residential electromagnetic
environment. The conformity is guaranteed by the implementation of the Harmonized Technical
Norms.
2.10 ENVIRONMENTAL CONDITIONS
The machine is designed to operate in indoor environments, with limited exposure to dust and
humidity and in an environment with a temperature ranging between 5°C and 40°C.
The machine can work in environments in temperatures less than 5°C or higher than 40°C only if
equipped with specific heating or cooling kits.
Environmental conditions different from those prescribed may cause breaking and malfunction.
Should environmental conditions be very variable, special measures will have to be agreed with
the Builder.
The machine is not designed to operate in explosive atmospheres. It is therefore forbidden to
use the machine in explosive atmospheres.
The machine has to be installed within a building with a strong and well-levelled flooring. The
building lighting has to comply with the laws in force in the country in which the machine is installed
and, in any case, it has to ensure adequate visibility on the whole working area that is also used for
the handling of products.
CEC BASE IGM REV13 23
