The
table rotation chain is protected by a plate fixed with screws to the frame.
The following pictures show where the chain is located showing it with and without fixed guard.
The
moving mechanisms of the film roll carriage located inside the column are protected by two
casings (A and B) fixed with screws, but just the lower one (B) must be removed to install the
machine.
A
B
