STANDARD CARRIAGE
CARRIAGE WITH DYNAMIC BRAKE
PRE-STRETCH CARRIAGE
WARNING! DO NOT LIFT THE
CARRIAGE OFF THE ROLLER!
Scr
ew the brackets fixed to the carriage to the brackets and distance pieces fixed to the column.
CEC BASE IGM REV13 36

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Omni Base and is the answer not in the manual?

Omni Base Specifications

General IconGeneral
Wrap Height Max80"
Film Width20"
Load Weight Max4000 lbs
Load Capacity4000 lb
Turntable Speed12 RPM
Wrapping Speed12 RPM
