4
Front Panel and LCD
You can get VOLT operational, select a preset, and flexibly adjust it for your station’s sound and
market …in minutes… entirely from the front panel!
Omnia’s exclusive QuickTweak system lets you completely customize
important internal processing parameters, including some that can’t be
reached through normal processing controls, with “master controls”
designed specifically for broadcast processing. Choose any preset. Use
QuickTweak to fine-tune its density, spectral balance, stereo soundstage,
clipping, and more. You can hear the results as you adjust the six QuickTweak controls… and
then name and save your customized “tweak” as a new preset.
Headphone
Gain Reduction
Output
LCD Jog
Input level
Wideband
Individual Bands
out volume
AGC Limiter
Mid
MidHi
Low
MidLo
Hi Mid
MidHi
Low
MidLo
Hi
11 Gate LEDs
(etc)
CompositeLeft
Right
Power
frontPanelWCallouts.pdf
All of these front-panel functions, and more, are accessible via password-protected login from
networked computers, tablets, or smartphones. There are more than 140 individual routing and
processing adjustments and selections available, along with comprehensive higher resolution
metering, preset management, firmware update, DSP|Core installation, and maintenance
functions. See the chapter on Remote Control.
Front Panel Headphone Jack
VOLT’s ¼” TRS stereo headphone jack monitors the processed signal. It is driven by a separate
high quality DAC and amplifier, independent of the analog XLR outputs. It has a separate vol-
ume control on the front panel.
CHAPTER 4
| 17
FRONT PANEL AND LCD
