© 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D
Appendix A: Part List A-3
53-7123 slide support bracket
rail
BRACKET,SLIDE,MOUNT,MAN. OVERRIDE,ATTACH
Installation Procedure
65-7009
65-7071
bin divider labels LABEL,NUMBERS,1-96,MATRIX,RX
LABEL,NUMBERS,1-24 MATRIX,RX
Labels
71-7008 (printer) PC card PCB ASSY,PRINTER,RIGHT ANGLE SHROUDED CONN
Printer PC Card
71-1054 elastomer KEYPAD,ELASTOMER,104-KEY,GREY
Elastomer
73-1001 speaker SPEAKER, 2.5", 8 OHM, 2W
Speaker
80-0802 speaker cable CONN,CABLE ASSY,MOLDED PLUG,3.5, STEREO, SHL'D, PVC, 36”
Electronics Tray
82-6061 jumper JUMPER,SHUNT,0.1",15AU,RED
Standardization Changes
88-1005 cabinet power/comm cable CABLE,POWER,SATA,6IN
Electronics Tray
88-6003 AUX cable CABLE,AUX,RJ12,6,LINE (DATA),25'
Electronics Tray
88-6014 flat panel cable CABLE,ASSY,REACH,CNTRLR,TO FLAT,PANEL
LCD Assembly
91-7040
91-7041
91-7044
slide SLIDE,OUTER HALF, DRAWER,RX,ACCURIDE C3834-156-1
SLIDE,OUTER HALF,SNAP-IN,ACCURIDE C3820-332-20L
SLIDE,INNER HALF,DRAWER,RX, SHORT, ACCURIDE C3834-156-2
Installation Procedure
94-6080 (transport handle) screw SCREW,BHCS,1/4-20,X,1/2,SS
Wireway
94-6132 (slide) screw
(rail) screw
SCREW,BH,TORX,8-32,X,3/16,SS
Installation Procedure
94-6137 (override cable) screw SCREW,BH,TORX,6-32,X,3/16,SS
Manual Override Cable
94-6151 (wireway) screw SCREW,FH,TORX,8-32,X,1/4,SS T15
Wireway
94-6158 (slide) washer WASHER,FLAT,#8,SS
Installation Procedure
94-6162 (printer support bracket) screws SCREW,FH,TORX,6-32,X,3/16,100,DEG,C'SINK
Manual Override Cable
(cable cover) screw SCREW,FH,TORX,6-32,X,3/16,100,DEG,C’SINK
Installation Procedure
Removal Procedure
Standardization Changes
(LCD bezel) screw SCREW,FH,TORX,6-32,X,3/16,100,DEG,C'SINK
LCD Screen
94-6167 (cable to frame front) nut NUT,EX,SMALL,HEX,10-32,1/4,X 3/32,SS
Manual Override Cable
94-6182 (cable to assembly) screw SCREW,TRUSS,HD,TORX,6-32,X 1/8,SS
Manual Override Cable
no part # LAN cable LAN cable (external vendor source?)
Electronics Tray
Part # Part Name Agile Description Where Used
Table A-1. TT Part List
