Appendix A: Part List
Link back to the procedure that calls out the given part using the cross reference in the Where Used
column.
Part # Part Name Agile Description Where Used
13-1129
13-1142
13-1136
13-1143
13-1150
13-1152
13-1151
13-1153
console lid MFG ASSY, LID, ETX, LVDS, RX-CT (old)
MFG ASSY, LID, LVDS, RX-CT, MOBILE CART (old)
MFG ASSY,LID W/O PTR,CE (old)
MFG ASSY, LID W/O PTR, MOBILE CART (old)
MFG ASSY, LID, ETX, LVDS, RX-CT (new)
MFG ASSY, LID, LVDS, RX-CT, MOBILE CART (new)
MFG ASSY,LID W/O APS PTR,CE (new)
MFG ASSY, LID W/O APS PTR, MOBILE CART (new)
LCD Assembly
Standardization Changes
keyboard cable (part of) MFG ASSY, LID, ETX, LVDS, RX-CT
Electronics Tray
nuts (part of) MFG ASSY, LID, ETX, LVDS, RX-CT
Keyboard
(console lid) screws (part of) MFG ASSY, LID, ETX, LVDS, RX-CT
LCD Assembly
(speaker) screws (part of) MFG ASSY, LID, ETX, LVDS, RX-CT
Speaker
14-1123 printer assembly MFG,ASSY,PRINTER,OMNIRX
Printer
platen lever (part of) MFG,ASSY,PRINTER,OMNIRX
Printer
Manual Override Cable
(printer to cover) screws (part of) MFG,ASSY,PRINTER,OMNIRX
Printer
(printer to frame) screws (part of) MFG,ASSY,PRINTER,OMNIRX
Printer
(printer) data cable (part of) MFG,ASSY,PRINTER,OMNIRX
Printer
(printer) PC board (part of) MFG,ASSY,PRINTER,OMNIRX
Printer
(printer PC card) screws (part of) MFG,ASSY,PRINTER,OMNIRX
Printer PC Card
14-1261 LCD assembly MFG ASSY, DISPLAY,ETX-REVC,LVDS,RX-CT
LCD Assembly
contrast cable (part of) MFG ASSY, DISPLAY,ETX-REVC,LVDS,RX-CT
Electronics Tray
14-7016 lit matrix drawer MODEL,OLMD24,24-LIT,MATRIX,DRAWER
Lit Matrix Drawers
14-7020
14-7021
unlit matrix drawer MODEL,OMD48,4/96-UNLIT,MATRIX,DRAWER
MODEL,OMD4,4-BIN,MATRIX DRAWER,(UNLIT)
Unlit Matrix Drawers
15-1040 PowerCom2 tray MFG,ASSY,MOTHERBOARD,ETX2 (inactive)
PowerCom2 Tray
15-7075
15-7076
dividers KIT,DIVIDER,24-BIN,LIT,MATRIX
KIT,DIVIDER,4/96,BIN,UNLIT,MTR
Unlit Matrix Drawers
Lit Matrix Drawers
15-9099 PowerCom 3 tray MFG ASSY, SLED, ELECTRONIC, PC3+
PowerCom3 CT PC Tray
40-3001 (drawer) controller board PCB,ASSY,DRAWER,CONTROLLER
Installation Procedure
Table A-1. TT Part List
