00039561.DOC, Version 1.2
13/37
USER MANUAL
PM-322 DJ Mixer
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
For your own safety, please read this user manual carefully before you initially start-up.
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet
1. INTRODUCTION
Thank you for having chosen the OMNITRONIC PM-322. If you follow the instructions given in this manual,
we are sure that you will enjoy this device for a long period of time.
Unpack your PM-322.
1.1 Features
Professional 2+1-channel DJ mixer
• 2 channels switchable to 2 phono, 2 line
• Channel 1+2 switchable between line and phono
• 1 separate DJ mic channel with input sensitivity control (gain), 2-fold tone control (bass, treble) and talkover
selector
• Microphone input via 1/4" mono jack on the faceplate
• High-quality and super-smooth channel faders
• Super-smooth crossfader replaceable from above
• Headphones output adjustable via Cue Level control
• Additional Cue Split/Cue Mix switch
• Cue Split function: the Cue signal is on the one side of the headphones and the output signal on the other
side
• Cue Mix function: the adjustable mix of Cue signal and output signal is on both sides of the headphones
• Mixing of the headphones signal possible via cue mixing fader
• Master out 10-fold LED level displays (L/R)
• Master control
• Rec Out independent from Master level for records with static level
