10. TECHNICAL SPECIFICATIONS
Power supply: 9 V AC, 500 mA
via power unit included in the delivery
Power consumption: 4.5 VA
Inputs: 2 phono, 4 line, 1 mic
Minimum input voltage:
Microphone: 2 mV, 4 kohms
Phono: 3 mV, 50 kohms
Line: 200 mV, 6 kohms
Output voltage: 4.5 V peak to peak
Outputs: 1 Master Out, 1 Rec Out via RCA
Frequency range: 20 - 20,000 Hz
Distortion: < 0.09 %
S/N ratio: -60 dB
Dimensions: 270 x 178 x 85 mm
Weight: 2 kg
Please note: Every information is subject to change without prior notice. 20.08.2008 ©
