7. CLEANING AND MAINTENANCE
Disconnectfrommainsbeforestartingmaintenanceoperation!
DANGERTOLIFE!
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers. Should you need any spare parts, please use genuine parts. Should you have
further questions, please contact your dealer.
7.1 Replacing the crossfader
Procedure:
Step 1: Remove the fader knob.
Step 2: Remove the two outer screws on the fader panel.
Step 3: Take the fader out and unplug the connection cable.
Step 4: Connect the new fader and fix it in the unit.
8.TECHNICAL SPECIFICATIONS
Power supply: 100-240 V AC, 50/60 Hz ~
Power consumption: 25 W
USB port: 2.0, type B
Inputs:
DJ MIC (front): combined 3-pin XLR/6.3 mm jack (bal.)
Impedance:
1 k
Minimum input voltage: 10 mV RMS
LINE 1-4: stereo RCA
Impedance:
1 k
Minimum input voltage: 300 mV RMS
PHONO 1,2: stereo RCA
Impedance:
1 k
Minimum input voltage: 3 mV RMS
Outputs:
MASTER: stereo RCA, XLR L/R (bal.)
Output voltage: 3 V RMS
REC: stereo RCA
Output voltage: 7 V RMS
Headphones:
6.3 mm stereo jack (T16 )
Tone control (DJ MIC):
1 x High: -30 dB to +12 dB/ 10 kHz, ±1 dB
1 x Low: -30 dB to +12 dB/ 100 Hz, ±1 dB
Tone control (CH 1-4):
1 x High: -30 dB to +12 dB/ 40 kHz, ±1 dB
1 x Low: -30 dB to +12 dB/ 40 kHz, ±1 dB
S/N ratio: 60 dB
Frequency range: 20-20,000 Hz
Dimensions (WxHxD): 483 x 177 x 101 mm (19", 4 U)
Weight: 2.9 kg
Please note: Every information is subject to change without prior notice. 15.05.2012 ©
