Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
J23
PID Control Restart
Feedback Deviation
after Stopping for
Process Control
0.0 to 100.0 %
0
Availa-
ble
%
page
7-123
J24
PID Control Restart
Delay Time after Stop-
ping for Process Con-
trol
0 to 3600 s
0
Availa-
ble
s
page
7-123
J57
PID Control Operator
PID Reference Posi-
tion for Dancer
-100 to 0 to 100 %
0
Availa-
ble
%
page
7-123
J58
PID Control PID Ref-
erence Position Detec-
tion Width for Dancer
0: Disable switching PID con-
stant
1 to 100 % (Manually set val-
ue)
0
Availa-
ble
%
page
7-123
J59 PID Control P Gain 2
0.000 to 30.000
0.1
Availa-
ble
-
page
7-123
J60
PID Control I Integral
Time 2
0.0 to 3600.0 s
0
Availa-
ble
s
page
7-123
J61
PID Control D Differ-
ential Time 2
0.00 to 600.00 s
0
Availa-
ble
s
page
7-123
J62
PID Control Block Se-
lection
Bit1: PID output ratio selection
0: Ratio to frequency com-
mand
1: Ratio to maximum frequen-
cy
Bit0: PID output polarity selec-
tion
0: Plus (Addition)
1: Minus (Subtraction)
0 - -
page
7-123
J63
Overload Stop Item
Selection
0: Torque
1: Current
0
Availa-
ble
-
page
7-153
4 Parameter List
4-145
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-9 Parameter J (Applied Functions 1)
