Pattern Operation / Timed Operation Mode Selection (Frequency
Reference Selection (F01/C30) = “10”)
• Refer to 5-5-3 Pattern Operation / Timed Operation Function on page 5-33.
Command Based on Pulse Train Input (Frequency Reference Selec-
tion (F01/C30) = “12”)
• Refer to 7-9-17 Pulse Train Frequency Input on page
7-145.
Command via Calculation Result of Frequency Calculation Func-
tion (Frequency Reference Selection (F01/C30) = “13”)
• Refer to 7-9-8 Frequency Calculation Function on page 7-118.
Command Based on Communication (Frequency Reference Selec-
tion (F01/C30) = “14”)
• Refer to Sec
tion 8 Communications Functions on page 8-1.
Frequency Reference Correlation Chart
Set the frequency reference at 1st Frequency Reference Selection (F01)/2nd Frequency Reference
Selection (C30).
Alternatively, the frequency reference can be switched via multifunction input. Below shows a chart
showing the correlation between priority, related parameters, and related multifunction input terminals
when the frequency reference is switched.
5 Basic Settings
5-31
M1 Series Standard Type User's Manual (I669)
5-5 Frequency Reference
5
5-5-1 Frequency Reference Selection
