Omron 3G3M1-A4007-ECT - Page 43

Single-phase 200 V, 2.2 kW
Three-phase 200 V, 3.7 kW
Three-phase 400 V, 3.0/4.0 kW
(4)
(3)
(6)
(5)
Single-phase 200 V, 3.7 kW
Three-phase 200 V, 5.5/7.5 kW
Three-phase 400 V, 5.5/7.5 kW
(4)
(3)
(2)
(1)
(5)
(6)
(1) Cooling Fan Cover (4) Inverter Case
(2) Cooling Fan (5) Surface cover (Terminal block cover)
(3) Cooling Fin (6) Surface cover (Backing plate)
1 Overview
1-9
M1 Series Standard Type User's Manual (I669)
1-2 Appearance and Part Names
1
