Three-phase 200 V, 11/15 kW
Three-phase 400 V, 11/15 kW
(2)
(1)
(3)
(4)
(6)
(5)
Three-phase 200 V, 18.5/22 kW
Three-phase 400 V
, 18.5/22 kW
(6)
(4)
(3)
(5)
(2)
(1)
(1) Cooling Fan Cover (4) Inverter Case
(2) Cooling Fan (5) Surface cover (Terminal block cover)
(3) Cooling Fin (6) Surface cover (Backing plate)
1 Overview
1-10
M1 Series Standard Type User's Manual (I669)
