Pushbutton Switch A16 G-25
Pushbutton
Switches
A16ZA-3003
A16ZT-3003A16ZJ-3003
Panel Plugs (Black Resin)
Select the Plug that fits the panel design and mount from the front of the Panel. Panel cutouts are the same as those for Switches.
Square
Round
Rectangular
12 x 12
17.9 ± 0.1
17.9
±
0.1
2
t=1
+0.2
0
Lock Ring
15.8±0.1 dia.
15 dia.
0
−0.1
Rough
surface
Rough surface
A16Z-5080
Extractor
