Zeitrelais H3DT
H3DT
H3DT-N/H3DT-L
9
Note: 1. The reset time is 0.1 s min. Make sure the signal input time is 0.05 s or longer.
2. “t” is the set time. “ta” is a time that is less that the set time.
E2: Interval (Power ON Start)
E3: Signal OFF Interval
F2: Cumulative (ON Delay)
F3:Cumulative (Interval)
tt − a t − at
Power (A1 and A2)
Time-limit contacts: NC
15 and 16 (25 and 26)
Time-limit contacts: NO
(output indicator)
15 and 18 (25 and 28)
Instantaneous contacts: NC
(21 and 22)
Instantaneous contacts: NO
(21 and 24)
Operation / Power indicator
Power
Output
Timing
Basic Operation
ttt − at − at − a
Power (A1 and A2)
Time-limit contacts: NC
15 and 16 (25 and 26)
Time-limit contacts: NO
(output indicator)
15 and 18 (25 and 28)
Instantaneous contacts: NC
(21 and 22)
Instantaneous contacts: NO
(21 and 24)
Operation / Power indicator
Start input (B1 and A1)
* The start input is valid while the Timer is in operation.
Power
Start input
Output
Timing
Basic Operation
t
t1+t2=t
t − a t1 t2
Power (A1 and A2)
Time-limit contacts: NC
15 and 16 (25 and 26)
Time-limit contacts: NO
(output indicator)
15 and 18 (25 and 28)
Instantaneous contacts: NC
(21 and 22)
Instantaneous contacts: NO
(21 and 24)
Operation / Power indicator
Start input (B1 and A1)
Timing Timing Holding
Power
Start input
Output
Note: Timing is performed while the start input is ON.
Basic Operation
Power (A1 and A2)
Time-limit contacts: NC
15 and 16 (25 and 26)
Time-limit contacts: NO
(output indicator)
15 and 18 (25 and 28)
Instantaneous contacts: NC
(21 and 22)
Instantaneous contacts: NO
(21 and 24)
Operation / Power indicator
Start input (B1 and A1)
t1+t2=t
t
t−a t1 t2
Timing Timing
Power
Start input
Output
Holding
Note: Timing is performed while the start input is ON.
Basic Operation
