Datenblatt
Zeitrelais H3DT
H3DT
H3DT
29
Track Mounting Products (Sold Separately) (Unit: mm)
Note: 1. Order the above products in multiples of 10.
2. The Tracks conform to DIN standards.
Options (Order Separately)
DIN Track
PFP-100N
PFP-50N
1
35
±0.3
7.3
±0.15
27
±0.15
4.5
15 25 25
10
15(5) *
10
25 25
* Dimensions in parentheses are for the PFP-50N.
1,000 (500) *
DIN Track
PFP-100N2
15 25 25
1,000
4.5
25 25 15
10
1
242735
±0.3
16
1.5
29.2
10
End Plate
PFP-M
4.8
1.3
35.5 35.3
1.8
1
1.8
10
6.2
M4 screw
and washer
50
11.5
M4x8
panhead
screw
10
Spacer
PFP-S
5
16
12
44.3
34.8
16.5
52.7
3.5
1.8
17.5
5.85
Front Cover
Y92A-D1A
Erstellt am 09.10.2020 um 23:38 Uhr | Alle Angaben ohne Gewähr, Irrtümer und Änderungen vorbehalten! Seite 30 von 37
