Irregular
heartbeat
2 times
Irregular
heartbeat
3 times
K
Movement error symbol
Appears with your reading when your body is moving during
a measurement. If it appears, remove the arm cuff and wait
for 2 to 3 minutes. Then, reapply the cuff, remain still and
take another measurement.
L
/
Irregular heartbeat symbol
• Appears when irregular rhythm is detected 2 or more
times during a measurement. The symbol with the
number appears as below:
Irregular heartbeat is detected 2 times:
Irregular heartbeat is detected 3 or more times:
• This symbol may be displayed when the monitor detects
arm movements while taking a measurement. Refer to
section 7 for more information.
An irregular heartbeat rhythm is defined as a rhythm that is
25 % less or 25 % more than the average rhythm detected
while your monitor is measuring blood pressure.
Short
Long
Irregular Heartbeat
Normal Heartbeat
If it continues to appear, it is recommended that you
consult with, and follow the directions of your
physician.
M
Pulse display / Memory number
• Pulse rate appears after the measurement.
• When pressing the button, the memory number appears for
approximately 2 seconds before the pulse rate shows again on the display.
13
