22
< TTL Input Unit >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-ID501
No replacement model
TTL Input Unit with connector for 32 inputs. The CJ Series does not have the
same type of Unit.
Use the CJ1W-ID231 24-VDC Input Unit or CJ1W-MD563 TTL I/O Unit instead.
5 VDC, 3.5 mA, Connector,
32 inputs (Special I/O)
< AC Input Units >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-IA121
CJ1W-IA111
100 VAC Input Unit with
terminal block for 8 inputs.
Replace this unit with a 100
VAC Input Unit with 16 inputs.
1) Terminal block
2) Input points (8 points → 16 points)
3) Input circuit specifications
Input impedance (9.7 kΩ → 14.5 kΩ)
ON voltage (60 VAC → 70 VAC)
4) Internal current consumption
(5 VDC: 10 mA → 90 mA)
100 to 120 VAC, 10 mA,
Terminal block, 8 inputs
100 to 120 VAC, 7 mA,
Terminal block, 16 inputs
C200H-IA221
CJ1W-IA201
200 VAC Input Unit with
terminal block for 8 inputs.
.
1) Terminal block
2) Input points (8 points → 8 points*)
*16 I/O bits (1 word) are allocated.
3) Internal current consumption
(5 VDC: 10 mA → 80 mA)
200 to 240 VAC, 10 mA,
Terminal block, 8 inputs
200 to 240 VAC, 9 mA,
Terminal block, 8 inputs
C200H-IA122/IA122V
CJ1W-IA111
100 VAC Input Unit with
terminal block for 16 inputs.
1) Terminal block
2) Input circuit specifications
Input impedance (9.7 kΩ → 14.5 kΩ)
ON voltage (60 VAC → 70 VAC)
3) Internal current consumption
(5 VDC: 10 mA → 90 mA)
100 to 120 VAC, 10 mA,
Terminal block, 16 inputs,
IA122V: Complying with EC
Directive
100 to 120 VAC, 7 mA,
Terminal block, 16 inputs
C200H-IA222/IA222V
CJ1W-IA201
200 VAC Input Unit with
terminal block for 16 inputs.
Replace this unit with two
200 VAC Input Units with 8
inputs.
1) Terminal block
2) No. of circuits (16 points/common x 1 circuit
→ 8 points/common x 1 circuit x 2)
3) Internal current consumption
(5 VDC: 10 mA
→
80 mA x 2)
200 to 240 VAC, 10 mA,
Terminal block, 16 inputs,
IA222V: Complying with EC
Directive
200 to 240 VAC, 9 mA,
Terminal block, 8 inputs
< AC/DC Input Units >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-IM211
CJ1W-ID211
AC/DC Input Unit with
terminal block for 8 inputs.
Replace this unit with a DC
Input Unit with 16 inputs.
*The CJ Series does not have
an AC/DC Input Unit. If this
Unit is used with AC inputs,
change the wiring for DC
inputs.
1) Terminal block
2) Input points (8 points → 16 points)
3) Input circuit specifications
Input voltage range
(12 to 24 VAC/VDC → 24 VDC)
Input impedance (2 kΩ → 3.3 kΩ)
ON voltage (10.2 VDC → 14.4 VDC)
OFF voltage (3 VDC → 5 VDC)
4) Internal current consumption
(5 VDC: 10 mA → 80 mA)
12 to 24 VAC/VDC ,
Terminal block, 8 inputs
24 VDC, 7 mA, Terminal block,
16 inputs
C200H-IM212
CJ1W-ID211
AC/DC Input Unit with
terminal block for 16 inputs.
Replace this unit with a DC
Input Unit with 16 inputs.
*The CJ Series does not have
an AC/DC Input Unit. If this
Unit is used with AC inputs,
change the wiring for DC
inputs.
1) Terminal block
2) No. of circuits (16 points/common x 1 circuit
→ 8 points/common x 2 circuits)
3) Input circuit specifications
Input voltage range (24 VAC/VDC → 24 VDC)
Input impedance (3 kΩ → 3.3 kΩ)
4) Internal power consumption
(5 VDC: 10 mA → 80 mA)
24 VAC/VDC , Terminal block,
16 inputs
24 VDC, 7 mA, Terminal block,
16 inputs
