Omron CJ1M-CPU series Replacement Guide

4
1.2 CJ1G/CJ2M specifications comparison
The table below lists the major difference in specifications of the CJ1G and CJ2M series.
Item
CJ1Ｇ-CPU4*H/CPU4*
CJ2M-CPU**
Number of I/O points
CPU42H/43H: 960 points
CPU44/45/44H/45H: 1280 points
2,560 points
Program capacity
CPU42H: 10k step
CPU43H: 20k step
CPU44/44H: 30k step
CPU45/45H: 60k step
CPU*1: 5k step
CPU*2: 10k step
CPU*3: 20k step
CPU*4: 30k step
CPU*5: 60k step
Data memory
32k words
32k words
EM
CPU*1 to *3: 1 bank (32k)
CPU*4 to *5: 4 banks (32k x 4)
Built-in I/O
-
Built-in CPU funciton will be available by
adding the CJ2M-MD211/CJ2M-MD212.
Up to two units can be mounted.
In:10 points/Out:6 points (when one unit is
used)
In:20 points/Out:12 points (when two units
are used)
Attention: It is possible to use the unit with
the CPU Unit of unit version 2.0 or later.
Length of instructions
1-7 steps/one instruction
1-30 steps/one instruction
Execution
time of
instruction
LD instruction
CPU4*H: 0.04us
CPU4*: 0.08us
0.04us
MOV instruction
CPU4*H: 0.20us
CPU4*: 0.29us
0.12us
Overhead processing time
CPU4*H : 0.3ms
CPU4*: 0.5ms
CPU3*: 270us
CPU1*: 160us
Maximum number of
connectable units
40 units
40 units
Maximum number of Expansion
Racks
3
3
Clock function
Equipped as a standard function
Equipped as a standard function
Dimensions (CPU Unit)
90(H)ｘ62(W)ｘ65(D) CPU1*: 90(H)ｘ31(W)ｘ75(D)
CPU3*: 90(H)ｘ62(W)ｘ75(D)
Programming software
CX-Programmer
CX-Programmer
Programmin
g device
connection
Programming
device for
personal
computer
< Peripheral port connection >
Connection with PC requires cables:
CS1W-CN*** or CS1W-
CN118 +
XW2Z-***S-**
< RS232C port connection >
Connection with PC requires cables:
XW2Z-***S-CV or XW2Z-***S(-V)
< Peripheral (USB) port >
A direct connection can be made between
the USB port of the personal computerand
the PLC using the commercially-available
USB cable
< Serial (RS232C) port connection >
Use the serial cable
(XW2Z-200S-CV/500S-CV) to connect the
PC and serial port on the CPU Unit. (The
CPU3* does not have the RS232C port on
it. Mount the RS232C option board
(CP1W-CIF01) and connect the cable with
the unit)
Programming
console
Available
C200H-PRO27
CQM1-PRO01
Not supported.
