9
．
Program
59
9.4.2. Lists of Allocations
The tables below list the addresses necessary to execute this program.
●CIO area
They are the fixed addresses determined by the unit address (unit number) that is set for
SCU.
Unit number 0 is used in this program.
Address Data type Variable name
1519.10 BOOL SequenceAbortCompletion_SCU_0_P2
1519.11 BOOL SequenceEndCompletion_SCU_0_P2
1519.15 BOOL ProtocolMacroExecuting_SCU_0_P2
1519 UINT ProtocolMacroErrorCode_SCU_0_P2
Additional Information
For details on the CIO area allocated to SCU, refer to 2-3-2. CIO Area of the CJ Series Serial
Communications Units OPERATION MANUAL (Cat. No. W336).
●Related auxiliary area
They are the fixed addresses determined by the communications port number (internal
logical port) specified in the program (PMCR instruction operands).
This program uses the communications port No. 7.
Address Data type Variable name
A202.07 BOOL CommPortEnabledFlag_P7
Additional Information
For information on the related auxiliary area for the PMCR instruction, refer to Related
Auxiliary Area Words and Bits in Serial Communications Instructions (PMCR) in SECTION 3.
Instructions of the CJ Series Programmable Controllers INSTRUCTIONS REFERENCE
MANUAL (Cat. No. W474).
