Omron CK5M-CPU 1 Series - Preparation for the Controller Setup

12
6.2. Preparation for the Controller Setup
Prepare the Controller settings.
Install Power PMAC IDE on the computer in advance.
Creation of a New Project
1
Turn on the power to the
Controller.
2
Start Power PMAC IDE.
* If the dialog for confirming
access rights appears upon
start-up, select starting of
Power PMAC IDE.
3
The Communication screen
appears. Specify the IP address
of the destination Controller and
click Connect.
* The IP address of the
Controller is set to
“192.168.0.200” by default.
* If necessary, change the
Windows IP address to
“192.168.0.X”.
4
Power PMAC IDE starts, and is
online to the Controller.
