Omron CK5M-CPU 1 Series User Manual

No. Step Description Reference
7 Construction of
the EtherNet/IP
network
*1
Settings of the
originator device
Configure the originator device set-
tings.
For details, refer to the manual for
the originator device.
Refer to the NJ/NX-series CPU Unit
Built-in EtherNet/IP Port User’
s
Manual (Cat. No. W506) when the
NJ/NX Series is used.
Settings of the
connection
Configure the connection settings. Refer to the Power PMAC IDE User
Manual (Cat. No. O016) for details.
8 Preparation for
setting the Mo-
tion Controller
Creation of a new
project
Connect the computer with the Support
Software installed to the Motion Con-
troller
, and then start Power PMAC IDE
and create a new project.
Refer to the Power PMAC IDE User
Manual (Cat. No. O016) for details.
Initialization of
the Controller
Use Power PMAC IDE to initialize the
Motion Controller.
Refer to the
Power PMAC IDE User
Manual (Cat. No. O016) for details.
9 Settings of the
Motion Control-
ler
operation
Motor settings Use Power PMAC IDE to set the motor
operations for the Motion Controller.
Refer to the Power PMAC IDE User
Manual (Cat. No. O016) for details.
Programming Create user programs on Power PMAC
IDE.
Refer to the Power PMAC User's
Manual (Cat. No. O014) and the
Power PMAC Software Reference
Manual (Cat. No. O015) for details.
10 Transferring project data and check-
ing the operation
Transfer the created project data and
check that operations work as expect-
ed.
Refer to the Power PMAC IDE User
Manual (Cat. No. O016) for details.
*1. Perform settings only when EtherNet/IP is used.
