8
CP1
Options and accessories
Option boards
RS-232C
Option Board
CP1W-ClF01
RS-422A/485
Option Board
CP1W-ClF11
Memory Cassette
CP1W-ME05M
LCD Option
Board
CP1W-DAM01
Ethernet Option
Board
CP1W-CIF41
RS-422A/485
(Isolated-type)
Option Board
CP1W-ClF12
DeviceNet I/O Link Unit
CPM1A-DRT21
Inputs: 32 bits
Outputs: 32 bits
CP1W-CN811
I/O Connecting Cable: 80 cm
I/O Connecting Cable
Temperature Sensor Unit CJ Unit Adapter
DeviceNet I/O
Link Unit
PROFIBUS-DP I/O Link Unit
CPM1A-PRT21
Inputs: 16 bits
Outputs: 16 bits
PROFIBUS-DP I/O
Link Unit
CompoBus/S I/O Link Unit
CP1W-SRT21
Inputs: 8 bits
Outputs: 8 bits
CompoBus/S I/O
Link Unit
CP1W-TS001
Thermocouple inputs: 2
CP1W-TS002
Thermocouple inputs: 4
CP1W-TS101
Platinum-resistance thermometer inputs: 2
CP1W-TS102
Platinum-resistance thermometer inputs: 4
CP1W-EXT01
CJ Unit adapter for use with CJ1H.
Includes CJ endplate.
Note: CPM1A Expansion Unit and Expansion I/O Units can be used with CP1H, CP1L or CP1E CPU Units under the
same conditions as for the CP1W.
CP1W/CPM1A Expansion Units include
I/O Connection Cables (in lengths of
approx. 6 cm) for side-by-side
connection.
Battery Set
Battery Set
CP1W-BAT01
Switch Input Board
USB Programming
Cable
CP1W-20EDR1
DC inputs: 12
Relay outputs: 8
CP1W-16ER
Relay outputs: 16
CP1W-40EDR
DC inputs : 24
Relay outputs: 16
CP1W-40EDT
DC inputs: 24
Transistor outputs (sinking): 16
CP1W-40EDT1
DC inputs: 24
Transistor outputs (sourcing): 16
CP1W-8ED
DC inputs: 8
CP1W-8ER
Relay outputs: 8
CP1W-8ET
Transistor outputs (sinking): 8
CP1W-8ET1
Transistor outputs (sourcing): 8
Expansion I/O Units
Analog Units
Analog Input Unit
CP1W-AD041
Analog inputs: 4 (resolution: 6,000)
Analog Output Unit
CP1W-DA041
Analog outputs: 4 (resolution: 6,000)
Analog I/O Unit
CP1W-MAD11
Analog inputs: 2 (resolution: 6,000)
Analog outputs: 1 (resolution: 6,000)
CP1W-32ER
Relay outputs: 32
CP1W-32ET
Transistor outputs (sinking): 32
CP1W-32ET1
Transistor outputs (sourcing): 32
CP1W-16ET
Transistor outputs (sinking): 16
CP1W-16ET1
Transistor outputs (sourcing): 16
CP1W-CN221
USB Programming cable
A-type male to B-type male,
Length: 1,8 m
Switch Input Board
CP1W-SWB06
