Operand3 First destination word:
When Operand 2=000
PLB High-speed counter 1 or 2, Linear
counting mode:
F8388608 to 08388607
PLB High-speed counter 1 or 2, Ring
counting mode:
00000000 to 00064999
When Operand 2 =001
PLB High-speed counter 1 or 2/Pulse
output 1, or 2:
D7:Pulse output status
D6: Pulse output completed
D5: Total number of pulse specified
D4:Deceleration of pulse frequency
D1:Hihg-speed counter underflow/
overflow
D0:High-speed counter comparison
status
When Operand 2=002
PLB High-speed counter 1 or 2
D7:Comparison Result flags for range 8
D6: Comparison Result flags for range 7
D0:Comparison Result flags for range 1
First destination word:
When Operand 2=#0000
High-speed counter 0 or 1, Linear mode, (Not
for incremental pulse input)
High-speed counter 2 or 3, Linear mode, (Not for
incremental pulse input) <CJ2M only>
= 80000000Hex to 7FFFFFFFHex
High-speed counter 0 or 1, Ring mode, Linear
mode (For incremental pulse input)
High-speed counter 2 or 3, Ring mode, Linear
mode (For incremental pulse input) <CJ2M
only>
= 00000000Hex to FFFFFFFFHex
When Operand 2 =#0001.
High-speed counter 0, 1
High-speed counter 2, 3 (CJ2M only)
D2: Count direction
D1: PV Overflow/Underflow Flag
D0: Comparison In-progress Flag
Pulse output 0, 1
Pulse output 2, 3 (CJ2M only)
D9: Interrupt input for interrupt feeding Error
Flag
D8: Interrupt Feeding In-progress Flag
D7: Pulse Output Stopped Error Flag
D6: At-origin Flag
D5: No-origin Flag
D4: Pulse Output In-progress Flag
D3: Pulse Output Completed Flag
D2: Pulse Output Amount Set Flag
D1: PV Overflow/Underflow Flag
D0: Pulse Output Status Flag
When Operand2=#0002
High-speed counter 0 or 1,
High-speed counter 2 or 3 <CJ2M only>
[Results for 8 Ranges]
D7: Comparison result 8
D6: Comparison result 7
to
D0: Comparison result 1
[Results for 32 Ranges] <CJ2M only>
(D+1)
D15: Comparison result 32
D14: Comparison result 31
to
D0: Comparison result 17
(D)
D15: Comparison result 16
D14: Comparison result 15
to
D0: Comparison result 1
