■ Output Unit
(1) If a different type of terminal block or connector is used, change the wiring.
(2) If the number of circuits increases, rewire the terminals to each common terminal.
(3) If the output specifications differ, make sure that the system operates correctly.
(4) The relay lifetime may vary depending on usage when the different relay is used. Refer to About Contact
Output Units under Appendix A Specifications of Basic I/O Units and High-density I/O Units in the
CS1G/H-CPU□□H CS Series Programmable Controllers OPERATION MANUAL (Cat. No. W339) for details.
(5) If internal current consumption is different, make sure the power supply capacity is large enough.
(6) If the voltage and current consumption of the external power supply differ, make sure the power supply
capacity is large enough.
(7) C200H-series Units can be used with CS1-series CPU Units.
(8) Refer to the related manuals for details. Although CS-series Units have basic functions of C200H-series Units,
some specifications may differ.
< Relay Output Units >
C200H-series Unit
Corresponding CS-series Unit
Description
Difference
C200H-OC223
CS1W-OC201
Relay Output Unit with
terminal block for 5 outputs
(independent contacts).
Replace this unit with a Relay
Output Unit with 8 outputs
(independent contacts).
1) Terminal block
2) Output points
(independent contacts 5 points → 8 points)
3) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
4) Internal current consumption
(5 VDC: 10 mA → 100 mA,
26 VDC: 46 mA → 48 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 5 outputs
(independent contacts)
250 VAC/120 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
C200H-OC224
CS1W-OC201
Relay Output Unit with
terminal block for 8 outputs
(independent contacts).
1) Terminal block
2) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
3) Internal current consumption
(5 VDC: 10 mA → 100 mA,
26 VDC: 75 mA → 48 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
250 VAC/120 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
C200H-OC224V, OC224N
CS1W-OC201
Relay Output Unit with
terminal block for 8 outputs
(independent contacts).
1) Terminal block
2) Output circuit specification
Used relay
3) Internal current consumption
(5 VDC: 10 mA →100 mA,
26 VDC: 90 mA → 48 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
250 VAC/120 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
C200H-OC221
CS1W-OC211
Relay Output Unit with
terminal block for 8 outputs.
Replace this unit with a Relay
Output Unit with 16 outputs.
1) Terminal block
2) Output points (8 points → 16 points)
3) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
4) Internal current consumption
(5 VDC: 10 mA → 100 mA,
26 VDC: 75 mA → 96 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
250 VAC/120 VDC, 2 A,
Terminal block, 16 outputs
C200H-OC222
CS1W-OC211
Relay Output Unit with
terminal block for 12 outputs.
Replace this unit with a Relay
Output Unit with 16 outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
5) Internal current consumption
(5 VDC: 10 mA → 100 mA,
26 VDC: 75 mA → 96 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 12 outputs
250 VAC/120 VDC, 2 A,
Terminal block, 16 outputs
C200H-OC222V, OC222N
CS1W-OC211
Relay Output Unit with
terminal block for 12 outputs.
Replace this unit with a Relay
Output Unit with 16 outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specification
Used relay
5) Internal current consumption
(5 VDC: 10 mA → 100 mA,
26 VDC: 90 mA → 96 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 12 outputs
250 VAC/120 VDC, 2 A,
Terminal block, 16 outputs
