Omron CS1G-CPU42H User Manual

I/O Memory Allocation Section 9-3
228
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A600 to
A603
Macro Area
Input
Words
When MCRO(099) is executed, it
copies the input data from the
specified source words (input
parameter words) to A600
through A603 and executes the
specified subroutine with that
input data.
Input data:
4 words
Same as
CS/CJ-series
PLC.
A604 to
A607
Macro Area
Output
Words
After the subroutine specified in
MCRO(099) has been executed,
the results of the subroutine are
transferred from A604 through
A607 to the specified destination
words.
(output parameter words).
Output
data:
4 words
Same as
CS/CJ-series
PLC.
A608 A60800 Inner Board
Restart Bit
Turn the corresponding bit ON to
restart (initialize) Inner Board 0 or
1.
The bit is turned OFF automati-
cally when the restart processing
is completed.
--- Not used.
A609 to
A613
A60900
to
A61315
Inner Board
User Inter-
face Area
The data transferred from the
CPU Unit to the Inner Board is
defined and used at the Inner
Board.
The contents of these words is
retained when the power is
turned ON.
--- Not used.
A61901 Peripheral
Port Set-
tings
Changing
Flag
ON while the peripheral port’s
communications settings are
being changed. This flag will be
turned ON when STUP(237) is
executed and it will be turned
OFF after the settings have been
changed.
1: Chang-
ing
0: Not
changing
Not used.
A619
A61902 RS-232C
Port Set-
tings
Changing
Flag
ON while the RS-232C port’s
communications settings are
being changed. This flag will be
turned ON when STUP(237) is
executed and it will be turned
OFF after the settings have been
changed.
1: Chang-
ing
0: Not
changing
Not used.
Communi-
cations Unit
0 Settings
Changing
Flag
A62001 Port 1
A62002 Port 2
A62003 Port 3
A620
A62004 Port 4
The corresponding flag will be
ON when the settings for that
port are being changed.
The flag will be turned ON when
STUP(237) is executed and it will
be turned OFF by an event is-
sued from the Serial Communi-
cations Unit after the settings
have been changed.
It is also possible for the user to
indicate a change in serial port
settings by turning these flags
ON.
1: Chang-
ing
0: Not
changing
Not used.
